Circle Diagram of Induction Motor

Wishlist Share
Share Course
Page Link
Share On Social Media

About Course

Circle Diagram of Induction Motor

Let us start our discussion on the Circle diagram, I will not discuss the actual circle diagram in this video, but teach some basics you will need to understand. Then we will draw a circle diagram for a series RL circuit with variable resistance and draw a circle diagram for a parallel circuit that has two branches.

also, we will start drawing the circle diagram for a simplified equivalent circuit of the Induction motor, a simplified equivalent circuit is the one where you neglect the stator parameters and we will finish drawing the circle diagram for a simplified equivalent circuit of Induction motor, a simplified equivalent circuit is the one where you neglect the stator parameters. We will see how we can get the rotor copper loss, converted power, etc for any slip value.

finally, we will start with the concept of drawing the circle diagram of the approximate equivalent circuit of the Induction motor, also continue developing the circle diagram, and we will define the rotor copper loss, stator copper loss, converted power values, and finally conclude by understanding what is the output line, and we shall define the OUTPUT LINE, TORQUE LINE, and also see the process of determining the Maximum Output, Maximum Induced Torque, Maximum power factor. this all in the Circle Diagram of Induction Motor Training.
Join to Circle Diagram of Induction Motor course>
Show More

What Will You Learn?

  • Learn Circle Diagram of Induction Motor principle
